Bearing Assembly Machine

Name: Bearing Assembly Machine
Brand: CIXI HOTO METALLIC PRODUCT CO.,LTD
Price: 200,000 INR
Availability: InStock

Price 200,000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Bearing Assembly Machine Specification

Structure
Rigid, Modular

Lubrication Type
Grease or Oil compatible

Precision Rating
ISO P0 - P5

Load Capacity
Up to 5 Tons (5,000 kg/hr assembly rate)

Number Of Rows
Single or Double (as required)

Outer Diameter
30 mm to 200 mm (depending on model)

Seals Type
Open, ZZ (Metal Shielded), 2RS (Rubber Sealed)

Retainer
Nylon or Brass (based on requirement)

Inner Diameter
10 mm to 120 mm (depending on customization)

Cage Material
Steel, Nylon, or Brass

Thickness
Machine footprint approx. 850 mm

Usage
Industrial

Material
Mild Steel

Use
Automated assembly of bearing units in manufacturing applications

Bearing Type
Deep Groove Ball Bearing Assemblies

Product Type
Bearing Assembly Machine

Bore Size
10 mm to 120 mm (customized)

Warranty
1 Year

Color
Blue

Weight
Approx. 800 kg

Operating Temperature
0C to 45C

Automation Grade
Fully Automatic

Noise Level
Less than 78 dB

Assembly Accuracy
0.02 mm

Power Consumption
3.5 kW

Operator Requirement
Single Operator

Ambient Humidity
85% RH

Production Rate
20-50 units per minute

Control System
PLC Touchscreen Interface

Voltage Requirement
220V/380V, 50Hz

Dimensions (L x W x H)
1500 mm x 1000 mm x 1650 mm

Air Pressure Needed
0.5-0.7 MPa

Safety Features
Emergency Stop, Interlocking Guards, Fault Alarm

Surface Finish
Powder-coated/Corrosion Resistant

Bearing Assembly Machine Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Ningbo or Shanghai port

Delivery Time
3 Days

Sample Policy
Within a certain price range free samples are available

Packaging Details
Tube packaging or small single color box

Main Export Market(s)
Western Europe, Africa, Asia, Eastern Europe, South America, Australia, Central America, Middle East, North America

Main Domestic Market
All India

Certifications
We have certificates of ISO9001-2008, ISO 14001-2004, OHSAS 18001-2007.

About Bearing Assembly Machine

Fully Automatic elevator type of assembling machine

Model : HO-HLT62

Production range : OD 22-170MM

Applicant Mainly used for inner and outer raceway measurement, inner &outer ring fitting and steel ball loading with the detection accuracy of 1um

Main Configurations as below , or you can customize your required brand

PLC :OMRON

CYLINDER : SMC

LINEAR RESISTANCE : SAKA

STEPPING SYSTEM: LOCAL BRAN

GUIDE :SHAC

SENSOR : LOCAL BRAND

High Precision Fully-Automatic Assembly

Engineered for efficiency, this machine automates the assembly process of deep groove ball bearings with single or double rows. Its PLC touchscreen interface streamlines operation, requiring only one operator. With an accuracy of 0.02 mm and a production rate of up to 50 units per minute, it meets demanding industrial standards.

Versatile Bearing Range and Compatibility

The machine handles a wide variety of bearing sizes-inner diameters of 10 mm to 120 mm and outer diameters from 30 mm to 200 mm. Compatible with different cage and retainer materials like steel, nylon, or brass, along with multiple seal types (Open, ZZ, 2RS), it suits diverse production needs.

Durable, Safe, and Operator-Friendly Design

Constructed from powder-coated, corrosion-resistant mild steel, the machine is built for long-term industrial use. It features advanced safety systems including emergency stop, interlocking guards, and audible fault alarms, all housed within a compact, modular frame suitable for a single operator.

FAQ's of Bearing Assembly Machine:

Q: How does the Bearing Assembly Machine ensure assembly accuracy?

A: The machine incorporates advanced alignment technology and precision controls, delivering consistent assembly accuracy within 0.02 mm, meeting ISO P0 to P5 precision ratings for deep groove ball bearings.

Q: What is the process for operating the machine?

A: Operation is managed through a PLC touchscreen interface, where the operator selects the required bearing specifications. The machine then automatically performs each assembly step, from component placement to final inspection, minimizing manual intervention.

Q: Where can the Bearing Assembly Machine be installed and used?

A: Designed for industrial manufacturing settings, the machine can be installed in factory assembly lines or dedicated bearing production facilities. Its compact dimensions allow integration into various production layouts.

Q: What types and sizes of bearings can this machine assemble?

A: The system assembles deep groove ball bearings with customizable inner diameters (10-120 mm) and outer diameters (30-200 mm). It supports both single and double row assemblies, with options for different cage and retainer materials.

Q: What are the safety features included with the machine?

A: For operator safety, the machine features an emergency stop button, interlocking guards to prevent access during operation, and a fault alarm system that alerts the user to any operational issues.

Q: How often should maintenance be performed and how is support handled?

A: Routine maintenance is recommended based on production volume, typically every few months. The machine includes a 1-year warranty, and technical support is available through the manufacturer or distributor in China.
