Deep Groove Ball Bearing 16 Series

Basic bearing no

Bore D

Outer  Diameter D

Width W

Radius r min

Basic load rating KN

Ball Complement

Open

Shielded sealed

mm

Inch

mm

Inch

mm

inch

mm

inch

mm

inch

Dynamic C

Static C

No.

Size (mm)

R4

6.350

.2500

15.875

.6250

4.98

.1960

4.98

.1960

0.3

.012

0.742

0.342

6

3.969

R6

9.525

.3750

22.225

.8750

5.56

.2188

7.14

.2812

0.4

.016

2.556

1.351

9

2.831

R8

12.700

.5000

28.575

1.1250

6.35

.2500

7.94

.3125

0.4

.016

3.912

2.245

7

3.969

R10

15.875

.6250

34.925

1.3750

7.14

.2812

8.73

.3438

0.8

.031

4.605

2.774

7

3.969

R12

19.050

.7500

41.275

1.6250

7.94

.3125

11.11

.4375

0.8

.031

7.246

4.445

7

3.969

99502H

15.875

.6250

34.925

1.3750

11

.4331

0.8

.031

4.605

2.774

7

3.969

Basic bearing no

Bore D

Outer Diameter D

Width W

Radius r min

Basic load rating KN

Ball Complement

mm

Inch

mm

Inch

mm

inch

mm

inch

Dynamic C

Static C

No

Size

1601

4.763

.1875

17.463

.6875

6.350

.2500

0.3

0.12

1.511

0.724

6

3.969

1602

6.350

.2500

17.463

.6875

6.350

.2500

0.3

0.12

1.511

0.724

9

2.831

1603

7.938

.3125

22.225

.8750

7.144

.2812

0.3

0.12

2.547

1.342

7

3.969

1604

9.525

.3750

22.225

.8750

7.144

.2812

0.38

.015

2.547

1.342

7

3.969

1605

7.938

.3125

23.109

.9062

7.938

.3125

0.3

.012

2.547

1.342

7

3.969

1606

9.525

.3750

23.109

.9062

7.938

.3125

0.38

.015

2.547

1.342

7

3.969

1607

11.113

.4375

23.109

.9062

7.938

.3125

0.38

.015

3.556

1.938

6

3.969
